SICK Lector85x Operating Instructions

MTBF 100,000h
7)
1)
Configurable digital inputs and digital outputs are not available.
2)
Maximum length of cable: 10m
3)
The typical power consumption depends on the product configuration. The specified value applies to
digital outputs without load.
4)
When the cover is open, the device no longer conforms with the specified protection class. Protect the
device against moisture and dust when the cover is open temporarily.
5)
Prerequisites:
•
The optics protection hood must be screwed tightly onto the device.
•
The cover on the top of the device is closed.
•
The cables plugged into the electrical connections must be screwed tight. Unused electrical con‐
nections are sealed off with a protective cap.
6)
Housing only, without lens and optics protection hood.
7)
At 25°C ambient operating temperature.
10.3 Dimensional drawing
Base device
P2
P1
P3
X2
X1
P2
P1
P3
X2
X1
P2
P1
P3
X2
X1
1
2
3
Lector 85x
40.3
(1.59)
0.9
(0.04)
46
(1.81)
90
(3.54)
21.4
(0.84)
75.6
(2.98)
7.2
(0.28)
102
(4.02)
22.2
(0.87)
13.6
(0.54)
97.8
(3.85)
15.9
(0.55)
143.4
(5.65)
min. 8 (0.31) - max. 87 (3.43)
Figure 13: Structure and device dimensions, unit: mm (inch), decimal separator: period
1
4 tapped blind holes, M2.5, 5.5mm deep, for mounting the spacer
2
2 M5 sliding nuts; 5.5mm deep; pivoting; as an alternative method of mounting the
device
3
4 M5 tapped blind holes, 5.5mm deep; for mounting the device
Complete device
Product type: V2D8505x–xxxxxxxxxx
10 TECHNICAL DATA
40
O P E R A T I N G I N S T R U C T I O N S | Lector85x CAN I/O 8027859/1KN0/2023-08-02 | SICK
Subject to change without notice
