SICK Lector85x Operating Instructions

Stacked code
types
PDF417
Code qualifica‐
tion
On the basis of ISO/IEC16022, ISO/IEC15415, ISO/IEC18004
Internal image
memory
Not available
10.5 Interfaces
Communication
interfaces
•
Ethernet 1/2
•
Ethernet 3
•
Ethernet via USB (RNDIS)
1)
•
CAN 1 (male connector, M12, 17-pin, A-coded)
•
CAN 2 (male connector, M12, 5-pin, A-coded)
•
Serial data interface
•
Serial service interface
Gigabit Ethernet Protocol: TCP/IP
Function:
•
Data interface (read result output)
•
service interface
•
FTP (image transfer)
Data transmission rate: 10/100/1,000Mbit/s
MAC address (device-specific), see type label
Serial RS-232, RS-422
Data transmission rate: 1.2kBaud…115.2kBaud
Digital inputs 2 (“Sensor 1”, “Sensor 2”), isolated
Function:
•
Encoder input
•
External trigger
Configurable digi‐
tal inputs and
digital outputs
2)
X1: 4 (“DIO 3”, “DIO 4”, “DIO 5”, “DIO 6”)
X2: 2 (“DIO 7”, “DIO 8”)
CAN Protocol: SICK CAN sensor network CSN (CAN Device)
Function: Data interface (read result output)
Data transmission rate: 500kbit/s
USB USB 2.0
Function:
•
Service interface for parameterization
•
Ethernet via USB (RNDIS)
1)

3)
Reading pulse Digital inputs, CAN, auto pulse (commissioning)
Optical displays 10 status LEDs
Operator interfa‐
ces
Web server
Configuration
software (param‐
eterization)
SOPASair
microSD memory
card
4)
Functions:
•
Cloning (external storage medium)
Data storage and
retrieval
Image and data storage via external FTP
10 TECHNICAL DATA
42
O P E R A T I N G I N S T R U C T I O N S | Lector85x CAN I/O 8027859/1KN0/2023-08-02 | SICK
Subject to change without notice
