12
MCS300P
·
Technical Information
·
8013265
V
1-2
·
©
SICK AG
Product Description
Subject
to ch
ange wit
hout n
otice
2.3
Circuit board
Electrical connections on the cir
cuit board in t
he sender unit
Fig.
2
Electrical connections in the sender unit
Pt100
Line: A
WG26-15
Controller 2 limiter
Controller 1 limiter
Controller 2
Controller 1 (cell)
Heater
s
Output voltage as mains vo
ltage
Capacity: Max. 550 VA (per output)
Line: A
WG24-12
Heater
Line
Pin
Heater 1
(cell)
L1
4
N5
PE
6
Heater 2
L1
7
N8
PE
9
CAN
Line
CAN1
(internal)
ISOGND
LOW
HIGH
CAN2
External I/O
ISOGND
LOW
HIGH
11
13
