SICK MCS300P User Manual

Operation
MCS300P · Technical Information · 8013265 V1-2 · © SICK AG 31
Subject to change without notice
Digital outputs (DOi)
Menu: MCS300P/Parameterization/I/O/Data/Digital outputs
This menu displays the digital outputs.
Analog inputs (AIi)
Menu: MCS300P/Parameterization/I/O/Data/Analog inputs
This menu serves to configure the analog inputs.
Analog outputs (AOi)
Menu: MCS300P/Parameterization/I/O/Data/Analog outputs
This menu serves to configure the analog outputs.
Designation Remark
Index Consecutive number of digital output (DO1, DO2, ....).
Module Topographical addressing (→ p. 29). Generated automatically.
Source Tag.
Inverted Checkmark: Output inverted.
Designation Remark
Index Consecutive number of analog input (AI1, AI2, ....).
Module Topographical addressing (→ p. 29). Generated automatically.
Name Freely selectable.
Unit Unit of variable read in.
Zero Select from input screen.
MR start Enter scaling for the connected analog signal.
MR end
Designation Remark
Index Consecutive number of analog output (AO1, AO2, ....).
Module Topographical addressing (→ p. 29). Generated automatically.
Source Tag.
Live Zero Select from input screen.
Progr. behavior Internal use.
MR start/end 1/2 Scales analog outputs of measuring range 1 or 2.
MR 1/2 active Checkmark: Measuring range 1 or 2 active.
Both checkmarks set: Automatic measuring range switch-over.
Hysteresis: 10 %.
