SICK MCS300P User Manual

30 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Operation
Subject to change without notice
3.5.3.2 Hardware map
Menu: Parameterization/I/O/Hardware map.
CAN bus address x
Display of existing I/O modules in selected CAN bus gateway.
3.5.3.3 Data
Menu: Parameterization/I/O/Data.
OPC outputs (OPCOi)
Menu: MCS300P/Parameterization/I/O/Data/OPC outputs
This menu assigns data from the MCS300P to the OPC output values.
Modbus outputs (MBOi)
Menu: MCS300P/Parameterization/I/O/Data/Modbus outputs
This menu assigns data from the MCS300P. to the Modbus output values.
Modbus inputs (MBIi)
Menu: MCS300P/Parameterization/I/O/Data/Modbus inputs
This menu serves to assign names to the tags of the Modbus inputs.
Digital inputs (DIi)
Menu: MCS300P/Parameterization/I/O/Data/Digital inputs
This menu displays the digital inputs.
The sequence of the modules shown must match the sequence of the modules
plugged in (starting at the gateway).
Designation Remark
Index Consecutive number of module
Plugged in Checkmark: Module is plugged in.
Type I/O module type
Designation Remark
Index Consecutive number of OPC output value.
Source Tag.
Designation Remark
Index Consecutive number of Modbus output value.
Source Tag.
Designation Remark
Index Consecutive number of Modbus input.
Name Freely selectable.
Designation Remark
Index Consecutive number of digital input (DI1, DI2, ....).
Module Topographical addressing (→ p. 29). Generated automatically.
Name Set fixed.
Inverted Checkmark: Read in inverted.
