28
MCS300P
·
Technical Information
·
8013265
V
1-2
·
©
SICK AG
Operation
Subject
to ch
ange wit
hout n
otice
3.5.2.3
Line writer
▸
Enter the desired i
dentifier
s (t
ags).
Scaling of measuring box:
→
p.
19, §
3.3
.1.1
▸
Scaling of time
axis
[Sec, Min or Hour]
Scaling of y-axis:
→
p.
19, §
3.3.1.1
The Measuring Screen t
hen has the following
appearance:
Measuring box
Line writer
27
