SICK MCS300P User Manual

40 MCS300P · Technical Information · 8013265 V1-2 · © SICK AG
Operation
Subject to change without notice
3.7 Maintenance
3.7.1 Tests
Menu: Maintenance/Tests
This menu serves to test the analog and digital interfaces.
● Digital inputs
● Digital outputs
● Analog inputs
● Analog outputs
Example: Digital inputs
3.7.2 Operating states
Menu: Maintenance/Operating state
This menu serves to switch on the operating states of the MCS300P.
▸ Click (highlight) the desired inter-
face and execute with "Test”.
● The "Save” field has no signifi-
cance.
● LED goes on: Status signal "Maintenance” is
switched on.
▸ System stop
▸ Switch to measuring operation.
▸ Switch to measuring operation
(after changes in menu: Parameterization/
Measuring component/...)
