SICK microScan3 Technical Information

Structure Data type Length in bytes Offset in bytes Description
~ ~ ~
Structure Data type Length in bytes Offset in bytes Description
~ ~ ~
Data from assembly 113 See assembly
113
16
Offset (Block
device status)
•
S
tatus of security function
•
Status standby state
•
Contamination warning
•
Contamination error
•
Reference contour monitoring
•
Manipulation
•
Cut-off path (safety-oriented)
•
Cut-off path (Not safety-related)
•
Current monitoring case
•
Reset required
•
Application error
•
Device error
~ ~ ~
The "device status" data block contains the same data as assembly 113.
ANNEX 7
8022708/2019-04-15 | SICK T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3
21
Subject to change without notice

SICK microScan3 Specifications

General

Scanning angle	275°
Power supply	24 V DC
Supply voltage	24 V DC ± 20%
Enclosure rating	IP65
Resolution	70 mm
Protective field range	5.5 m
Number of fields	128
Interface	Ethernet
Safety integrity level	SIL3
Performance level	PL e
Ambient temperature	+50°C
Scanning range	5.5 m
