SICK microScan3 Technical Information

Table 5: Assembly 113
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved ManipulationStatus ReferenceCon‐
t
ourStatus
ContaminationError ContaminationWarn‐
ing
StandbymodeActive RunModeactive
1
1)
SafeCutOffPath08 SafeCutOffPath07 SafeCutOffPath06 SafeCutOffPath05 SafeCutOffPath04 SafeCutOffPath03 SafeCutOffPath02 SafeCutOffPath01
2
1)
SafeCutOffPath16 SafeCutOffPath15 SafeCutOffPath14 SafeCutOffPath13 SafeCutOffPath12 SafeCutOffPath11 SafeCutOffPath10 SafeCutOffPath09
3 Reserved SafeCutOffPath20 SafeCutOffPath19 SafeCutOffPath18 SafeCutOffPath17
4
1)
NonsafeCutOff‐
P
ath08
NonsafeCutOff‐
Path07
NonsafeCutOff‐
Path06
NonsafeCutOff‐
Path05
NonsafeCutOff‐
Path04
NonsafeCutOff‐
Path03
NonsafeCutOff‐
Path02
NonsafeCutOff‐
Path01
5
1)
NonsafeCutOff‐
Path16
NonsafeCutOff‐
Path15
NonsafeCutOff‐
Path14
NonsafeCutOff‐
Path13
NonsafeCutOff‐
Path12
NonsafeCutOff‐
Path11
NonsafeCutOff‐
Path10
NonsafeCutOff‐
Path09
6 Reserved NonsafeCutOff‐
P
ath20
NonsafeCutOff‐
Path19
NonsafeCutOff‐
Path18
NonsafeCutOff‐
Path17
7
1)
ResetRequiredCut‐
OffPath08
ResetRequiredCut‐
OffPath07
ResetRequiredCut‐
OffPath06
ResetRequiredCut‐
OffPath05
ResetRequiredCut‐
OffPath04
ResetRequiredCut‐
OffPath03
ResetRequiredCut‐
OffPath02
ResetRequiredCut‐
OffPath01
8
1)
ResetRequiredCut‐
OffPath16
ResetRequiredCut‐
OffPath15
ResetRequiredCut‐
OffPath14
ResetRequiredCut‐
OffPath13
ResetRequiredCut‐
OffPath12
ResetRequiredCut‐
OffPath11
ResetRequiredCut‐
OffPath10
ResetRequiredCut‐
OffPath09
9 Reserved ResetRequiredCut‐
Of
fPath20
NonsafeCutOff‐
Path19
ResetRequiredCut‐
OffPath18
ResetRequiredCut‐
OffPath17
10 Current Monitoring Case No (Table 1)
11
2)
Current Monitoring Case No (Table 2)
12
2)
Current Monitoring Case No (Table 3)
13
2)
Current Monitoring Case No (Table 4)
14 Reserved
15 Reserved DeviceError ApplicationError
1)
The number of available cut-off paths depends on the device variant.
2)
The safety laser scanner currently only supports one monitoring case table.
