SICK microScan3 Technical Information

Communication example
T
able 24: FirmwareVersion: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 35 2d ba 75 00 02
52 49 04 00
..........5-.u..
RI..
Table 25: FirmwareVersion: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 14 00 00 35 2d ba 75 00 02
52 41 04 00 06 00 52 30 31 2e 31 33
..........5-.u..
RA....R01.13
7.3.1.1.3 Type code
Overview
Name TypeCode
Index 13
Data type FlexString (length ≤ 32)
User group Run
Access rights Read
Description
The variable only offers read access.
The variable contains the type code of the device.
The value is output as a string (ISO 8859-15).
Communication example
T
able 26: TypeCode: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 38 41 5a 71 00 02
52 49 0d 00
..........8AZq..
RI..
Table 27: TypeCode: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 20 00 00 38 41 5a 71 00 02
52 41 0d 00 12 00 4d 49 43 53 33 2d 41 42 41 5a
35 35 49 5a 31 00 00 00
....... ..8AZq..
RA....MICS3-ABAZ
55IZ1...
7.3.1.1.4 Part number
Overview
Name OrderNumber
Index 14
Data type FlexString (length ≤ 32)
User group Run
Access rights Read
Description
T
he variable only offers read access.
The variable contains the part number of the device.
ANNEX 7
8022708/2019-04-15 | SICK T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3
39
Subject to change without notice
