Page #40 background imageLoading...
Page #40 background image
The value is output as a string (ISO 8859-15).
Communication example
T
able 28: OrderNumber: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 af 90 a7 6d 00 02
52 49 0e 00
.............m..
RI..
Table 29: OrderNumber: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 15 00 00 af 90 a7 6d 00 02
52 41 0e 00 07 00 31 30 37 35 38 34 38
.............m..
RA....107584
7.3.1.2 Configuration
7.3.1.2.1 Device name
Overview
Name DeviceName
Index 17
Data type FlexString (length ≤ 32)
User group Run
Access rights Read
Description
T
he variable only offers read access.
The variable contains the configured name of the device.
The value is output as a string (ISO 8859-15).
Communication example
T
able 30: DeviceName: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 49 ec b2 01 00 02
52 49 11 00
..........I.....
RI..
Table 31: DeviceName: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 1a 00 00 49 ec b2 01 00 02
52 41 11 00 0c 00 4d 79 44 65 76 69 63 65 4e 61
6d 65
..........I.....
RA....MyDeviceNa
me
7.3.1.2.2 Project name
Overview
Name ProjectName
Index 18
Data type FlexString (length ≤ 32)
User group Run
Access rights Read
7 ANNEX
40
T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3 8022708/2019-04-15 | SICK
Subject to change without notice
