Communication example
T
able 35: cigen_tApplicationName: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 b3 a2 a4 11 00 02
52 49 21 00
................
RI!.
Table 36: cigen_tApplicationName: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 34 00 00 b3 a2 a4 11 00 02
52 41 21 00 56 01 00 00 11 00 00 00 4d 79 41 70
70 6c 69 63 61 74 69 6f 6e 4e 61 6d 65 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00
.......4........
RA!.V.......MyAp
plicationName...
............
7.3.1.2.4 User name
Overview
Name cigen_tUserName
Index 35
Data type Structure
User group Run
Access rights Read
Description
T
he variable only offers read access.
The variable contains the configured name of the user.
The value is output as a string (ISO 8859-15).
Structure
T
able 37: cigen_tApplicationName: Structure
Data field Data type Length in
b
ytes
Offset in
bytes
Description
tVersion cVersion USInt 1 0 0: The values of this variable are invalid. Other
values: valid.
u8Major USInt 1 1 Main version number. Different numbers stand
f
or incompatible versions.
u8Minor USInt 1 2 Sub version number. Versions with different sub
version numbers are compatible if the main ver‐
sions numbers are the same.
u8Release USInt 1 3 Release number.
tName u32Length UDInt 4 4 Length of the string: Number of the bytes used in
au8Data.
au8Data Array
(U
SInt)
32 8 Content of the string. Bytes not used contain
zeroes.
Communication example
T
able 38: cigen_tUserName: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 f6 36 a1 fd 00 02
52 49 23 00
...........6....
RI#.
7 ANNEX
42
