SICK microScan3 Technical Information

Table 39: cigen_tUserName: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 2c 00 00 f6 36 a1 fd 00 02
52 41 23 00 56 01 00 00 0a 00 00 00 4d 79 55 73
65 72 4e 61 6d 65 00 00 00 00 00 00 00 00 00 00
00 00 00 00
.......,...6....
RA#.V.......MyUs
erName..........
....
7.3.1.2.5 Metadata of the configuration
Overview
Name cigen_tConfigMetadata
Index 28
Data type Structure
User group Run
Access rights Read
Description
T
he variable only offers read access.
The variable contains the checksum of the configuration and the date and time of the
last change and configuration transmission.
Configuration of the fields, field sets and monitoring cases can be called up via other
variables. Additional information is available from your SICK subsidiary.
Structure
T
able 40: cigen_tConfigMetadata: Structure
Data field Data type Length in
b
ytes
Offset in
bytes
Description
tVersion cVersion USInt 1 0 0: The values of this variable are invalid. Other
values: valid.
u8Major USInt 1 1 Main version number. Different numbers stand
for incompatible versions.
u8Minor USInt 1 2 Sub version number. Versions with different sub
v
ersion numbers are compatible if the main ver‐
sions numbers are the same.
u8Release USInt 1 3 Release number.
tModification‐
Time
tDate UInt 2 4 Date:
•
If real-time clock is available: days since
01.01.1972
•
If no real-time clock is available: number of
full 24-hour cycles since device was switched
on.
Reserved 2 6
tTime UDInt 4 8 Time:
•
If r
eal-time clock is available: milliseconds
after midnight.
•
If no real-time clock is available: milliseconds
since the start of the current 24-hour cycle
since switching on the device.
ANNEX 7
8022708/2019-04-15 | SICK T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3
43
Subject to change without notice
