SICK microScan3 Technical Information

Data field Data type Length in
b
ytes
Offset in
bytes
Description
Reserved 2 8
Reserved 2 10
tCurrentTime u32PowerOn‐
C
ount
UDInt 4 12
tTime UDInt 4 16 Time:
•
If r
eal-time clock is available: milliseconds
after midnight.
•
If no real-time clock is available: milliseconds
since the start of the current 24-hour cycle
since switching on the device.
tDate UInt 2 20 Date:
•
If real-time clock is available: days since
01.01.1972
•
If no real-time clock is available: number of
full 24-hour cycles since device was switched
on.
Reserved 2 22
tErrorInfo u32Code UDInt 4 24 Error code as on the display of the device (only if
error is present).
Reserved 16 28
Reserved 8 44
tTime UDInt 4 52 Time:
•
If r
eal-time clock is available: milliseconds
after midnight.
•
If no real-time clock is available: milliseconds
since the start of the current 24-hour cycle
since switching on the device.
tDate UInt 2 56 Date:
•
If r
eal-time clock is available: days since
01.01.1972
•
If no real-time clock is available: number of
full 24-hour cycles since device was switched
on.
Reserved 2 58
Reserved 4 60
Communication example
Table 45: Cigen_tStatusOverview: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 a0 03 08 a1 00 02
52 49 17 00
................
RI..
Table 46: Cigen_tStatusOverview: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 4c 00 00 a0 03 08 a1 00 02
52 41 17 00 52 01 00 00 00 05 04 00 00 00 00 00
b5 02 00 00 41 b6 d4 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
af 01 00 00
.......L........
RA..R...........
....A...........
................
................
....
7 ANNEX
46
T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3 8022708/2019-04-15 | SICK
Subject to change without notice
