Communication example
T
able 49: DeviceStatus: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 59 ac 3f 69 00 02
52 49 0f 00
..........Y.?i..
RI..
Table 50: DeviceStatus: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0d 00 00 59 ac 3f 69 00 02
52 41 0f 00 03
..........Y.?i..
RA...
7.3.1.3.3 Note on troubleshooting
Overview
Name RequiredUserAction
Index 16
Data type Cont
User group Run
Access rights Read
Description
Together with the variables "DeviceStatus", the variable "RequiredUserAction" provides
information on troubleshooting.
Table 51: RequiredUserAction: Values
Value (Cont) Meaning
0x0001
(
b0000 0000 0000 0001)
Configure device, verify configuration
0x0002
(
b0000 0000 0000 0010)
Test configuration, test device variant
0x0004
(
b0000 0000 0000 0100)
Check communication partner, check manipu‐
lation
0x0008
(
b0000 0000 0000 1000)
Check input signals, check network and other
connections
0x0010
(
b0000 0000 0001 0000)
Check the error messages
0x0020
(
b0000 0000 0010 0000)
Configure device (including network settings)
0x0040
(
b0000 0000 0100 0000)
Checking the firmware
0x0080
(
b0000 0000 1000 0000)
Wait a few seconds
Communication example
T
able 52: RequiredUserAction: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 59 ac 3f 69 00 03
52 49 10 00
..........Y.?i..
RI..
7 ANNEX
48
T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3 8022708/2019-04-15 | SICK
Subject to change without notice

SICK microScan3 Specifications

General

Scanning angle	275°
Power supply	24 V DC
Supply voltage	24 V DC ± 20%
Enclosure rating	IP65
Resolution	70 mm
Protective field range	5.5 m
Number of fields	128
Interface	Ethernet
Safety integrity level	SIL3
Performance level	PL e
Ambient temperature	+50°C
Scanning range	5.5 m
