SICK microScan3 Technical Information

Table 53: RequiredUserAction: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0e 00 00 59 ac 3f 69 00 03
52 41 10 0000 00
..........Y.?i..
RA....
7.3.1.3.4 Device temperature
Overview
Name FrontendApp_tSenderDiagnostics
Index 362
Data type Structure
User group Run
Access rights Read
Description
T
he variable only offers read access.
The variable contains the temperature that is measured in the device´s sender module.
The temperature value can serve as an approximate guide for the interior temperature
of the device. The value can significantly deviate from the specified operating tempera‐
ture.
Structure
T
able 54: cigen_tApplicationName: Structure
Data field Data type Length in
b
ytes
Offset in
bytes
Description
Reserved 6 0
i16Temperature Int 2 6 Temperature in 0.1 °C
Reserved 8 8
Communication example
T
able 55: FrontendApp_tSenderDiagnostics: Variable recall
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 3c f5 29 13 00 03
52 49 6a 01
..........<.)...
RIj.
Table 56: FrontendApp_tSenderDiagnostics: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 1c 00 00 3c f5 29 13 00 03
52 41 6a 01 02 00 7a 13 dc 38 75 01 68 32 9a 3d
00 00 69 13
..........<.)...
RAj...z..8u.h2.=
..i.
ANNEX 7
8022708/2019-04-15 | SICK T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3
49
Subject to change without notice

SICK microScan3 Specifications

General

Scanning angle	275°
Power supply	24 V DC
Supply voltage	24 V DC ± 20%
Enclosure rating	IP65
Resolution	70 mm
Protective field range	5.5 m
Number of fields	128
Interface	Ethernet
Safety integrity level	SIL3
Performance level	PL e
Ambient temperature	+50°C
Scanning range	5.5 m
