13 Technical data
Table 12: Technical data
Cylinder type C-slot
Detection zone 0 ... 50 mm
1)
Supply voltage U
B
10 ... 30 V DC
Power consumption ≤ 550 mW
Required magnetic field strength, typ. ≥ 2 mT
overrun distance can be configured
Hysteresis can be configured
Time delay before availability 0.15 s
Resolution typ. 0.01 mm
Linearity typ. 0.3 mm
2)
Repeatability typ. 0.05 mm
3)
Sampling rate min. 2 kHz
IO-Link 1.1
Enclosure rating IP67
Protection class III
Circuit protection A, B, D
4)
Ambient temperature, operation –20 °C ... +70 °C
1)
Deviations are possible depending on the drive.
2)
At 25 °C, the linearity error (maximum deviation) depends on response curve and minimum deviation
func
tion.
3)
At 25 °C, repeatability with magnet movement from one direction.
4)
A = UB connections reverse polarity protected
B = Inputs and outputs reverse polarity protected
C = Interference suppression
D = Outputs overcurrent and short-circuit protected
TECHNICAL DATA 13
8025942/2020-07-16 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2 / 3 switching points and IO-Link (up to 16 switching points)
