13.1 Dimensional drawing
25,3
11,15
L1
1
2
37,8
L = 500
345
3,8
2,9
6
3,6
7
15,9
9,1
36 - 41,5
M8 x 1
8
Pin 1
Pin 2 Pin 4
Pin 3
2,9
Figure 13: Dimensional drawing with male connector, M8 knurled
