Q2
PWR
Q1
Q2
PWR
Q1
Q2
PWR
Q1
Q2
PWR
Q1
f f
fi
Q2
PWR
Q1
s
s s
f f
fi fi
si
s
s
x
1x
3 - 5 sec
(v
ery long)
Delete
Qint
Action not preformed if button is released before
re
quest time start
Reset Menu
Action preformed if button is
released within request time
Action not preformed if button is
released after request time end
0 sec 1 sec 1.2 sec 3 sec 5 sec time
LED behaviour
Off
On
Slow blink
Inverted slow blink
Fast blink
Inverted fast blink
Tallymark blink
* Qint = switch point
Qint
succ
e
ssfully deleted
Figure 10: Dynamic Teac
h teach routine
Flashing tally sheet:
1 mm = 1 x brief flash
2 mm = 2 x brief flashes
3 mm = 3 x brief flashes
4 mm = 4 x brief flashes
5 mm = 1 x long flash
8.3.2 Manual Teach
Manual Teach is used t
o manuall
y teach in up to three switching points within the measuring range using the teach-
in button. The three switching points are taught in separately from each other (taking into account the set switch‐
ing point width, the positions must be at least 1 mm apart to be detected as different positions).
NOTE
Aft
er Manual Teach is run, the width of the switching point (see "Switching behavior after Manual Teach of up to 3
switching points", page 12) can be set.
OPERATION 8
8025942/2020-07-16 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-G with 2 / 3 switching points and IO-Link (up to 16 switching points)
31
Subject to change without notice
