SICK MPS-G 1108675 - Page 30

Move
Q2
PWR
Q1
Q2
PWR
Q1
s
s s
Q2
PWR
Q1
s s
Q2
PWR
Q1
f f
Regular Operation Teach Menu
Dynamic Teach
Enter Teach
Menu
2x
ca.
0.5
sec
(short)
1x
ca.
0.5 sec
(short)
Enter Manual
Te
ach menu
1x
ca.
1.5 sec
(long)
Start
1x
ca.
1.5 sec
(long)
Finish Teach
→ Sa
ve changes
→ Exit teach menu
→ Q1-LED lights up for Qint1,
→ Q2-LED lights up for Qint2,
→ Q1- and Q2-LED light up
→ same time for Qint3
Move piston and stop at
de
si
red position for Qint*
→ Qints are set at v = 0 m/s
(up to 3 Qints possible)
End
No stops found?
→ Exi
t teach menu
without changes
8 OPERATION
30
