Stroke time in positive
direc
tion
Duration of the last stroke in the positive direction in ms.
The positive direction goes in the direction of the sensor fixing
screw.
One stroke corresponds to movement in a direction. Direction of
movement for extending stroke: End position - start position.
The start position is the direction of the cable outlet of the sensor.
The end position is in the direction of the sensor fixing screw.
Total cylinder travel Total piston travel in m.
