5.5 Locking and unlocking release button
Approach
5.6 Mounting device
Approach
1. Unlock the device.
2. Remove the device from the clamping bracket with the release button pressed.
3. Swivel or rotate the device.
MOUNTING
5
8027772//2022-08-11 | SICK O P E R A T I N G I N S T R U C T I O N S | UC40
15
Subject to change without notice
