10.3 Performance
Operating range UC40-11211x: 65mm...350mm
UC40-11311x: 200mm ... 1,300mm
UC40-11411x: 350mm ... 3,400mm
Limiting range UC40-11211x: 600mm
UC40-11311x: 2,000mm
UC40-11411x: 5,000mm
Measuring object Natural objects
Resolution UC40-11211x: ≥0.1mm
UC40-11311x: ≥1mm
UC40-11411x: ≥1mm
Repeatability ± 0.15%
1)
Accuracy ± 1%
2)3)
Temperature compen‐
sation
Temperature compensation
Response time
4)
UC40-11211x: 64ms
UC40-11311x: 96ms
UC40-11411x: 160ms
Switching frequency UC40-11211x: 10Hz
UC40-11311x: 7Hz
UC40-11411x: 4Hz
Output time UC40-11211x: 16ms
UC40-11311x: 24ms
UC40-11411x: 41.6ms
Ultrasonic frequency
(typical)
UC40-11211x: 400kHz
UC40-11311x: 200kHz
UC40-11411x: 120kHz
Detection range (typi‐
cal)
Detection ranges
Additional function Adjustable switching point modes: switching point (Single Point Mode) / switching window (Window
Mode) / background (Window Mode 8%), teachable digital output, parameterizable digital output,
invertible digital output, adjustable switch-on delay digital output, teachable analog output, parame‐
terizable analog output, invertible analog output, automatic switching between current and voltage
output, analog output switchable to second digital output, synchronization of up to 50 sensors,
multiplexing: no mutual interference of up to 50 sensors, adjustable measurement filters: measured
value filter / filter strength / foreground suppression / detection range / sensitivity and sound lobe /
false echo suppression, teach-in buttons (can be deactivated), reset to factory settings
1)
Relative to the current measured value, minimum value ≥ resolution.
2)
Relative to the current measured value.
3)
Temperature compensation can be switched off, not temperature compensated: 0.17% / K.
4)
Subsequent smoothing of the analog output may increase the response time by up to 200% in some applications.
10.4 Interfaces
IO-Link IO-Link V1.1
Function: Process data, configuration, diagnostics, data storage
Digital output Quantity: 1
Type: Push-pull: PNP/NPN
1)
Maximum output current I
A
: ≤ 100 mA
TECHNICAL DATA 10
8027772//2022-08-11 | SICK O P E R A T I N G I N S T R U C T I O N S | UC40
39
Subject to change without notice
