10 Technical data
NOTE
The relevant online product page for your product, including technical data, dimensional
drawing, and connection diagrams, can be downloaded, saved, and printed from the
Internet.
It can be called up via SICK ProductID: pid.sick.com/{P/N}
{P/N} corresponds to the part number of the product (see type label).
Please note: This documentation may contain further technical data.
10.1 Mechanics/Electronics
Supply voltage V
S
DC 9 V...30 V
1)2)
Power consumption ≤ 1.5 W
3)
Initialization time < 300 ms
Design Cuboid
Housingmaterial plastic (PA66)
Ultrasonic transducer: polyurethane foam, epoxy resin
Connection type Male connector, M12, 5-pin
Display 4 x LED
Weight UC40-11211x: 120g
UC40-11311x: 120g
UC40-11411x: 130g
Sending axis Straight
Dimensions (W x H x D) 40 mm x 40 mm x 66 mm
Enclosure rating IP65/IP67
Protection class III
Scope of delivery Push-lock mounting system (1x)
1)
Limit values, reverse-polarity protected. Operation in short-circuit protected network: max. 8A, class 2.
2)
15 V...30 V when using the analog voltage output.
3)
Without load
10 TECHNICAL DATA
36
O P E R A T I N G I N S T R U C T I O N S | UC40 8027772//2022-08-11 | SICK
Subject to change without notice
