10.2 Dimensioned drawing
UC40-11211x
M12 x 1
40
(1.57)
5.3
(0.21)
14
(0.55)
66
(2.6)
60
(2.36)
40
(1.57)
40
(1.57)
7.3
(0.29)
1
(0.04)
Ø 5.5 (2x)
(Ø 0.22)
20
(0.79)
R 2.8 (2x)
(0.11)
30
(1.18)
42.3
(1.67)
40
(1.57)
40
(1.57)
Ø 10
(Ø 0.39)
1
2
Figure 7: Structure and device dimensions, unit of measurement: mm (inch), decimal separator: point
1
2 fixing holes; radius: 2.8 mm
2
2 fixing holes; diameter: 5.5 mm
TECHNICAL DATA 10
8027772//2022-08-11 | SICK O P E R A T I N G I N S T R U C T I O N S | UC40
37
Subject to change without notice
