1
Digital output of the device (“Result 1” to “Result 4”)
2
Output signal
3
Output voltage V
out
4
With inductive load: see note
!... "
For pin assignment, see respective device
Table 15: Characteristic data of the digital outputs
Switching behavior PNP switching to supply voltage V
S
Default: No function
Logic: not inverted (active high)
Properties
Short-circuit protected
Not electrically isolated from V
S
1)
Electrical values 0 V ≤ V
out
2)
≤ V
S
(V
S
−1.5 V) ≤ V
out
≤ V
S
at I
out
3)
≤ 100 mA
1)
Supply voltage.
2)
Output voltage.
3)
Output current.
NOTE
Provide an arc-suppression switch at the digital output if inductive load is present.
b
Attach a freewheeling diode directly to the load for this purpose.
NOTE
Capacitive loads on the digital outputs have an effect on the switch-on and switch-off
behavior. A maximum capacitance of 100 nF is the limit value.
Function assignment
NOTE
Assign the functions for the digital outputs in the device using a configuration tool, e.g.
the configuration software SOPAS ET.
Extension: additional logical digital outputs in the device for physical external digital
outputs on the optional connection module
Thanks to the optional CMC600 parameter cloning module in combination with the CDB
or CDM connection module, the two digital outputs “External output 1” and “External
output 2” are additionally available at the relevant terminals of the connection module.
NOTE
The external digital outputs are software-controlled and therefore do not offer the same
timing precision as physical digital outputs. The external digital outputs may not be suit‐
able for time-critical applications.
For the electrical characteristic data of the two external digital outputs, see the respec‐
tive connection diagrams for the connection modules in these operating instructions.
Wiring the digital outputs of the device via a connection module:
ELECTRICAL INSTALLATION 6
8018071/16XD/2020-05-06 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector63x Flex C-mount and S-mount
51
Subject to change without notice
