Connection mod‐
ules
Digital outputs Reference
CDB650-204 "RES/OUT 1"
"RES/OUT 2"
"RES/OUT 3"
"RES/OUT 4"
see "Wiring digital outputs of the
device in the CDB650-204",
page 83
External output 1 (“EXT. OUT 1”)
External output 2 (“EXT. OUT 2")
see "Wiring the external digital out‐
puts of the device in the
CDB650-204", page 84
CDM420-0006 "Result 1"
“Result 2”
see "Wiring digital outputs of the
device in the CDM420-0006",
page 96
External output 1 (“AUX Out 1”)
External output 2 (“AUX Out 2”)
see "Wiring the external digital out‐
puts of the device in the
CDM420-0006", page 97
6 ELECTRICAL INSTALLATION
52
O P E R A T I N G I N S T R U C T I O N S | Lector63x Flex C-mount and S-mount 8018071/16XD/2020-05-06 | SICK
Subject to change without notice
