SICK WLL190T-2 - Selection of the Menu Levels

Selection of the menu levels
Teach-in
 
 �
Custom configuration
  
1.1 Max. Teach-in
1.2 1-point Teach-in
1.3 2-point Teach-in
1.4 Auto Teach-in
1.5 Zone Teach-in
1.6 Teach-in of transparent objects
2.1 Switching mode
2.2 Response time
2.3 Time delay setting
2.4 Autom. sensitivity correction
2.5 Expert menu/detailed settings
2.6 Reset
EXIT back to operating mode
3.1 Set display value to zero
3.2 Display settings
3.3 Detection mode
3.4 Counter setting
3.5 Input/output setting
3.6 External input function
3.7 APC setting
3.8 ASC setting
3.9 Strength setting of the sender LED
3.10 Copy mode
3.11 Set display value to zero
3.12 Master Teach-in
3.13 Selection, analogue menu
EXIT back to basic menu
4.1 Activation of analogue output
4.2 Range adjustment
4.3 Def. of invalid measurement values
4.4 Average values
4.5 Setting of extreme value memory
EXIT back to Expert menu
P. 6
P. 7
P. 8
P. 9
P. 10
P. 11
P. 12
P. 13
P. 14
P. 15
P. 16
P. 17
P. 18
P. 19
P. 20
P. 21
P. 22
P. 23
P. 24
P. 25
P. 26
P. 27
P. 28
P. 29
P. 30
P. 31
P. 32
P. 33
P. 34
P. 35
2 SENSICK
2007-08-24
Photoelectric switch for fibre-optic cables WLL190T-2 
Easy handling, structured functions and maximum
functionality.
The photoelectric switch for fibre-optic cables WLL190T-2 with the SICK
fibre-optic cables is especially suited to detecting very small objects,
objects in front of interfering backgrounds, and transparent and moving
objects. Fibre-optic cables are ideal for use in installations where space
is restricted.
Locking, fibre-
optic cable
Status LEDs for
switching outputs
Numeric display for
nominal value (green)
and actual value (red)
Arrow keys
Mode/Enter
key
Set/Run
selector switch
Teach-in key
