Risk symbol Description
Potentially risk of injury when working on machines with open covers/
doors
Risk of injury due to flying objects
Destruction risk of electrostatically sensitive components
Risk of property damage
1.2 Illustration of General Notices
Symbol Description
Hint with additional, further information
Tip with suggestions and useful information
1.3 Technical Symbols
Symbol
Description
LED indicator: LED on
LED indicator: LED off
LED indicator: LED flashes
1.4 Abbreviations
FPAM flux pulse amplitude modulation
HSBLOCK high-speed block commutation
HSPAM high-speed pulse amplitude modulation
HSPWM high-speed pulse width modulation
n.c. not connected
OSSD Output Signal Switching Device
PAM pulse amplitude modulation
PWM pulse width modulation
SERVO servo control
About this Manual
W
10 Drive System SD2S - Hardware Description 0362X49xy / 0362129xy
