9 Setup
When connecting and setting up the installation consider the safety instruc‐
tions and the manual “Unit Assembly Complying EMC”.
9.1 SD2S Connection and Switch-on
For wiring also read the
chapter 11 "General Information Regarding the Wiring",
page 89.
The following connectors must be wired at the least:
▶ mains supply (L1, L2, L3, PE)
▶ motor phases (U, V, W, PE)
▶ OSSD (safety circuit)
▶ communication with PC (e.g. USB port)
▶ external ballast resistor or bridge for internal ballast resistor
We recommend also to connect the digital input D-IN2 with a quick stop
function.
Before switch-on install the software
drivemaster2
on the connected PC.
➮ Switch on the device now.
➮ Check the device status by means of the status display (see section 10.2 "7-
segment display", page 82). As soon as the controller is ready, you can set the
parameters of SD2S in the software
drivemaster2
and put the device into opera‐
tion.
9.2 Parameter Setting and Initial Operation
For detailed information on the parameters and initial operation with the software
drive‐
master2
refer to the documentation “drivemaster2 - User Manual”. In addition, the
following quick start guides are available depending on the required drive function:
▶ SD2S Setup Instructions – V/f Operation
▶ SD2S Setup Instructions – Sensorless Vector Control (SVC)
W
Setup
Drive System SD2S - Hardware Description 0362X49xy / 0362129xy 79
