8 Connection Examples

The following sections provide connection examples for the individual connectors of

the device.

A wiring example for the device connection it to find in the

Appendix, page 107.

8.1 X6, X7 – Incremental Encoder with TTL Signals

Encoder signals: 5V

Connection Examples

Drive System SD2S - Hardware Description 0362X49xy / 0362129xy 55
