Connector Meaning Description
X63 External ballast resistor page 52
X64 OUT EtherCAT slave output page 52
X65 IN EtherCAT slave input
Device housing ground page 78
SK 14 Mounting holes for shield connection clamp SK 14 by Phoenix
(comprised in connector kit)
page 77
You can order the appropriate connector kit for the device variants
0362X49xy and 0362129xy at SIEB & MEYER under article number
32299600.
Device Description
W
36 Drive System SD2S - Hardware Description 0362X49xy / 0362129xy
