Specification of Drive Functions
Drive function SERVO / VECTOR VF
Analog outputs
2 outputs
Operating range 0 – 10 V
Maximum range 0 – 10 V
Resolution internal 14 Bit
Sampling 4 kHz (250 µs)
Function to be configured via software
ENC0
Input
Signal A Quad B, pulse/direction, CW/CCW
Maximum input frequency 2.5 MHz per track
Level RS422
Encoder
ENC1/
EMU
ENC1/EMU as input
Signal A Quad B
Maximum input/output frequency 2.5 MHz per track
Level RS422
ENC1/EMU as output
Signal A Quad B / pulse output
Maximum input/output frequency 2.5 MHz per track
Level RS422 (3.3 V)
Monitorings
Drive function SERVO / VECTOR VF
Monitoring functions
Measuring systems
Power supply unit: load
Power supply unit: charge monitoring overvoltage
Power supply unit: charge monitoring undervoltage
Power output stage: load (I²t)
Power output stage: temperature
Power output stage: short circuit (U, V, W, PE)
Power output stage: safety circuit
Motor: load (I²t)
Motor: temperature (PTC, NTC, KTY84/130)
Motor: motor phase missing
DC link: overvoltage
DC link: undervoltage
Ballast circuit: load
Ambient temperature
Speed: error / slip
Speed: overspeed
Position: tracking error (only with interpolated position control and elec-
tronic gear)
184 Drive System SD2 - Hardware Description
