10.1 Rear Panel with Liquid Cooling

This solution is suited for high performance applications:

Fig. 75: Mounting the SD2 to a rear panel with liquid cooling

The complete solution “Direct Cooling Package”, for example, is available at Rittal.

Note

Pay attention to the safety instructions of the cooling system. Make sure that sufficient

protection against condensation is used.

99Drive System SD2 - Hardware Description

Mounting Example with External Heat Sink
