Dimensions
Fig.
32
:
Dimensions
of
0362114QF
in
mm
(inch)
Fig. 32: Dimensions of 03621
14QF in mm (inch)
Note
For
the
installation
consider
that
the
heads
of
the
cabinet
screws
located
on
the
long
sides of
each
module
overlap up
to
2 mm.
This
causes
a module
gap
of
at least
4
mm
when several modules are combined in an assembly group.
55
Drive System SD2 - Hardware Description
Single-axis Drive Amplifiers
54
56
