Drive Amplifier SD2
5.4 Components of the Drive System SD2x
The following table shows an overview of all devices described in this document. The
article numbers of these devices begin with 03621:
03621... Device
type
Sin-
gle-axis
Dou-
ble-axis
Width
approx.
[mm]
Heat
transfer
plate
(1)
Integr.
high-per-
formance
heat sink
Integr. wa-
ter-cool
ed heat
sink
Integr.
pow-
er sup-
ply unit
Description
10xy – ✔ 70 ✔ – – – page 59
11xy ✔ – 70 ✔ – – – page 25
11MF/NF ✔ – 130 ✔ – – – page 29
11OF ✔ – 130 – – ✔ – page 33
11RF ✔ – 230 – – ✔ – page 37
11SF ✔ – 230 – – ✔ – page 41
12xxy – ✔ 100 ✔ – – – page 63
13xxy – ✔ 70 – ✔ – – page 67
14xy ✔ – 70 – ✔ – – page 46
14MF/NF ✔ – 130 – ✔ – – page 50
15xxy
SD2
drive ampli-
fier
– ✔ 100 – ✔ – – page 71
30xxy – ✔ 100 ✔ – – ✔ page 75
31xxy
SD2
compact
devices
– ✔ 100 – ✔ – ✔
page 79
90y ✔ – 70 ✔ – – ✔ page 86
91y ✔ – 70 – ✔ – ✔ page 90
93y
PS2
power sup-
ply units
✔ –
153.5
(2)
159
(3)
– ✔ – ✔
page 94
(1)
These devices are to be mounted on the customer's own heat sink (see chapter 10).
(2)
Measured without screws
(3)
Measured with screws
Other SD2x devices
The following list contains all other devices of the drive system SD2x. These devices
are described in separate documents. The article numbers of these devices begin with
0362x:
▸
036231x: SD2 drive amplifiers including the safety functions SFM and SLOF
▸
036212x: SD2S Light compact devices
▸
0362x4x: SD2S compact devices
– 036214x: SD2S without fieldbus interface
– 036224x: SD2S with EtherCAT interface
▸
036215X: various optional devices
▸
036216x: SD2T devices in table top design
▸
036217x: SD2B / SD2B plus board devices (single-board design)
▸
036228x: SD2M multilevel devices with EtherCAT interface
Additional equipment
The following additional equipment is also available at SIEB & MEYER and compatible
with SD2x drives:
▸
USB>RS232/485 converter 050201 (for a detailed description refer to separate
document)
24 Drive System SD2 - Hardware Description
