SIEB & MEYER SD2S User Manual

7.4.2 Technical Data
Device variant 0362115EIC 0362115EIF
Rated current (8 kHz) 14 A
p
+ 28 A
p
/
10 A
rms
+ 20 A
rms
10 A
p
+ 24 A
p
/
7 A
rms
+ 17 A
rms
Rated current (16 kHz) -- 9.2 A
p
+ 18.4 A
p
/
6.5 A
rms
+ 13 A
rms
Peak current of the output stages 40 A
p
+ 80 A
p
40 A
p
+ 80 A
p
Max. time for peak current 2 s 2 s + 1 s
Max. temperature of the output stage 75° C
Max. output frequency 2000 Hz
Output frequency stability ≤ 0.2 %
DC link voltage 40 to 325 V
DC
+10 % 40 to 680 V
DC
+10%
Logic supply 18 to 28 V
DC
Power loss logic unit 12 W
Power loss of power unit Max. 5 % of the output motor power, at least 20 W
Overvoltage threshold 410 V
DC
850 V
DC
Undervoltage threshold 40 V
DC
Ambient temperature range 5 °C to 60 °C at a maximum relative humid-
ity of 85 % (without moisture condensation),
100 % rated current up to max. 40 °C. At higher temper-
atures the power must be reduced by -1.5 % per 1 °C.
IP Code IP20
Max. weight 7.2 kg
