SIEB & MEYER SD2S User Manual

Power Supply Unit PS2
9.3.2 Technical Data
Device variant 0362191F
min. 3 × 110 V
AC
-20 %three-phase
max. 3 × 480 V
AC
+10 %
min. 1 × 110 V
AC
-20 %
Mains supply L1, L2, L3
(1)
single-phase (LN)
only with 0362191F1
max. 1 × 230 V
AC
+20 %
up to 110 V
AC
6.2 kW
up to 230 V
AC
13 kW
Max. rated power
up to 480 V
AC
27 kW
Logic supply 18 to 28 V
DC
(max. 0.4 A at 24 V
DC
)
three-phase max. 3 × 40 AProtective fuse L1, L2, L3
single-phase max. 1 × 40 A
Ballast resistor up to 230 V
AC
, min. 10 Ω /
> 230 V
AC
min. 22 Ω
Max. heat sink temperature 75° C
Ambient temperature 0 to 40 °C without power reduction, max. 60 °C
Above 40 °C the power must be reduced by 1.5 % per 1 °C.
Humidity up to 85 % (without moisture condensation)
Capacity of DC link 495 µF
Max. weight 5.8 kg
(1)
For power chokes refer to Manufacturers.
