Siemens 1FT7 Configuration Manual

Connection system
6.2 Signal connection
1FT7 Synchronous Motors
228 Configuration Manual, (PFT7S) 01/2009, 6SN1197-0AD13-0BP2
Cables
In order to prevent interference (e.g. due to EMC) and ensure safe electrical isolation, the
power cables and signal cables must be separately routed.
Prefabricated cables from Siemens (MOTION-CONNECT) must be used. These offer many
advantages over cables made by other manufacturers in terms of operational reliability,
quality, and cost.
Table 6- 5 Pre-assembled cable for incremental encoder
6FX ☐ 002 - 2CA31 - ☐☐☐ 0
↓
5 MOTION-
CONNECTⓇ500
8 MOTION-
CONNECTⓇ800
↓↓↓
Length, max. cable length 50 m
Table 6- 6 Prefabricated cable for absolute encoder
6FX ☐ 002 - 2EQ10 - ☐☐☐ 0
↓
5 MOTION-
CONNECTⓇ500
8 MOTION-
CONNECTⓇ800
↓↓↓
Length, max. cable length 50 m
For other technical data and length code, refer to Catalog, Chapter "MOTION-CONNECT
connection system"
