Siemens 1FT7 Configuration Manual

Description of the motors
1.5 Selection and ordering data
1FT7 Synchronous Motors
Configuration Manual, (PFT7S) 01/2009, 6SN1197-0AD13-0BP2
23
1FT7 Compact standard type
1)
The current carrying capacity of the power cables complies with EN 60204-1 for installation type C, for continuous duty at an ambient air
temperature of 40 °C (104 °F).
2)
With default setting of the pulse frequency.
3)
Motor type
(continued)
Static
current
Calculated
power
P
calc
3)
SINAMICS S120 Motor Module Power cable with complete shield
Motor connection (and brake connection) via
power connector
Rated
output
current
2)
Booksize format
I
0
at M
0
Δ T=100 K
P
calc
for M
0
ΔT=100 K
I
rated
Power
connector
Cable
cross-
section
1)
Pre-assembled cable
A kW (HP) A Order No. Size mm
2
Order No.
1FT7102-5AB7...
1FT7105-5AB7...
1FT7108-5AB7...
9
15
18
4.71 (6.32)
7.85 (10.5)
10.99 (14.7)
9
18
18
6SL3127 - 7TE21 - 0AA3
6SL3127 - 7TE21 - 8AA3
6SL3127 - 7TE21 - 8AA3
1.5
1.5
1.5
4 x 1.5
4 x 1.5
4 x 2.5
6FX7 002 - 57S21 - ....
6FX7 002 - 57S21 - ....
6FX7 002 - 57S31 - ....
Cooling:
Internal air cooling
External air cooling
0
1
Motor Module:
Single Motor Module
Double Motor Module
Type of power cable:
MOTION-CONNECT 800
MOTION-CONNECT 500
Without brake cores
With brake cores
For length code as well as power and signal cables, see Connection system MOTION-CONNECT.
1
2
8
5
C
D
....
P
calc
[kW] =
M
0
[Nm] x n
rated
9550
P
calc
[HP] =
M
0
[Ib
f
-in] x n
rated
63000
