Description of the motors
1.5 Selection and ordering data
1FT7 Synchronous Motors
24 Configuration Manual, (PFT7S) 01/2009, 6SN1197-0AD13-0BP2
1FT7 Compact standard type
Rated
speed
Shaft
height
Rated
power
Static
torque
Rated
torque
Rated
current
1FT7 Compact
synchronous motors
Natural cooling
Standard type
Num-
ber of
pole
pairs
Rotor moment
of inertia
(without brake)
Weight
(without
brake)
n
rated
SH P
rated
at
ΔT=100 K
M
0
at
ΔT=100 K
M
rated
at
ΔT=100 K
I
rated
at
ΔT=100 K
Jm
rpm kW
(HP)
Nm
(lb
f
-ft)
Nm
(lb
f
-ft)
AOrder No. 10
-4
kgm
2
(10
-3
lb
f
-in-s
2
)
kg
(lb)
2000 80 2.39 (3.20)
3.54 (4.75)
4.71 (6.32)
13 (9.6)
20 (14.8)
28 (20.7)
11.4 (8.4)
16.9 (12.5)
22.5 (16.6)
4.9
8.4
9.2
1FT7082 - 5AC7 7 - 1 7 7 7
1FT7084 - 5AC7 7 - 1 7 7 7
1FT7086 - 5AC7 7 - 1 7 7 7
5
5
5
26.5 (23.5)
45.1 (39.9)
63.6 (56.3)
14 (30.9)
20.8 (45.9)
27.5 (60.6)
100 5.03 (6.75)
7.96 (10.7)
10.5 (14.1)
30 (22.1)
50 (36.9)
70 (51.6)
24.0 (17.7)
38.0 (28.0)
50.0 (36.9)
10
15
18
1FT7102 - 5AC7 7 - 1 7 7 7
1FT7105 - 5AC7 7 - 1 7 7 7
1FT7108 - 5AC7 7 - 1 7 7 7
5
5
5
91.4 (80.9)
178 (157)
248 (219)
26.1 (57.5)
44.2 (97.5)
59 (130)
Type of construction IM B5: Flange 0
Flange 1 (compatible with 1FT6)
0
1
Encoder systems for motors
without
DRIVE-CLiQ interface:
Incremental encoder sin/cos 1 V
pp
2048 S/R
with C and D tracks
Absolute encoder EnDat 2 048 S/R
Encoder systems for motors
with DRIVE-CLiQ interface:
22 bit incremental encoder with commutation position
Absolute encoder, 22 bit single-turn +12 bit multi-turn
D
F
Shaft extension:
Fitted key and keyway
Fitted key and keyway
Fitted key and keyway
Fitted key and keyway
Plain shaft
Plain shaft
Plain shaft
Plain shaft
Shaft and flange accuracy:
Tolerance N
Tolerance N
Tolerance R
Tolerance R
Tolerance N
Tolerance N
Tolerance R
Tolerance R
Holding brake:
without
with
without
with
without
with
without
with
Vibration magnitude:
Grade A
Grade A
Grade A
Grade R
Grade R
Grade R
Degree of protection:
IP64
IP65
IP67
IP64
IP65
IP67
N
M
A
B
D
E
G
H
K
L
0
1
2
3
4
5
