Engineering and remote access
3.6 SITOP UPS Manager
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
121
● Downtime alarm: The time in which no alarm is issued to the system although it is
buffered.
● Wait time for stable input voltage: The time in which no alarm is issued to the system
although the connection threshold has been undershot.
● R test interval: The time interval between battery tests can be set using the parameter.
To reset the parameters to their initial value, click the "Reset to initial values" button. All
parameters for the base device will be reset to their initial value.
Configuring the energy storage
The characteristic values of a SITOP UPS1100 battery module are automatically read by the
coding. If a SITOP UPS1100 battery module is used, activate the "SITOP UPS1100 battery"
checkbox.
If you are using a different battery, activate the "Use third-party battery" checkbox. Enter the
rated values of the other battery. The following parameters are available under "Hardware
configuration> Energy storage".
End-of-charge voltage 24 - 30 V
Faulty battery voltage 1 - 18 V
● Battery capacity: Total capacity of the installed batteries
● End-of-charge voltage: The charging completes when the selected end-of-charge voltage
is reached.
● Charge current: The battery is not charged with more than the selected charge current.
The manufacturer's details for the permitted charge current of the battery must be
observed. If several batteries are connected, the smallest permitted charge current
applies.
● Faulty battery voltage: If the battery voltage falls below this value, it will be considered as
being defective by the SITOP UPS1600 and is not charged.
To reset the parameters to their initial value, click the "Reset to initial values" button. All
parameters for the energy storage will be reset to their initial value.
