Engineering and remote access
3.6 SITOP UPS Manager
SITOP UPS1600 / UPS1100
128 Manual, 04.2017, A5E37775406-8-76
● Open the SITOP UPS Manager if there is a connection to the SITOP UPS1600.
● Open the SITOP UPS Manager if the connection to the SITOP UPS1600 was interrupted.
Behavior for pending system alarms
Make the settings under "Software configuration > System alarms". Reasons for a system
alarm are contained in the alarms list (see Section Troubleshooting (Page 183)).
The following options exist in the "System alarms" submenu:
● Start the application if at least one system alarm is active.
● Start the application if no system alarm is active.
● Open the SITOP UPS Manager if at least one system alarm is active.
● Open the SITOP UPS Manager if no system alarm is active.
Display and visualization
The "Display" menu item shows information about the device data and parameters as well as
the state of the power supply.
The following display options exist:
● Active alarms
● Alarm history
● Operating data: Data and parameters of the basic device and the energy storage device
● Trend charts:
– Load current over time
– Input voltage over time
– Remaining buffer time over time
Note
From the instant in time when the SITOP
UPS1600 is switched over into the buffer
mode, to determine the expected buffer time, instead of the expe
cted buffer current,
the actually measured buffer current is used.
– Battery temperature over time
– Battery charge over time
– Charge current over time
● Online functions:
– Updating the firmware
