Siemens 6EP4135-0GB00-0AY0

Technical data
8.5 Protection and monitoring
SITOP UPS1600 / UPS1100
216 Manual, 04.2017, A5E37775406-8-76
8.5
Protection and monitoring
Table 8- 2 SITOP UPS1600
6EP4134-3AB00- ... (10 A)
6EP4136-3AB00- ... (20 A)
6EP4137-3AB00- ... (40 A)
Current limitation
Typ.
• Remark
30 A
Power boost with 300 % I
out rated
for typ. 30 ms
60 A
Power boost with 300 % I
out rated
for typ. 30 ms
120 A
Power boost with 300 % I
out rated
for typ. 30 ms
Short-circuit protec-
tion
Shutdown after 30 ms
Reverse polarity
protection
With respect to the input voltage U
in
and with respect to batteries
Overload/short-circuit
indicator
Yes, restart in normal operation
Table 8- 3 SITOP UPS1100
6EP4131-
0GB00-...
(1.2 Ah)
6EP4132-
0GB00-...
(2.5 Ah)
6EP4133-
0GB00-...
(3.2 Ah)
6EP4133-
0JB00-...
(5 Ah)
6EP4134-
0GB00-...
(7 Ah)
6EP4135-
0GB00-...
(12 Ah)
Short-circuit
protection
Yes, fuse
Reverse
polarity pro-
tection
Yes
8.6
MTBF
6EP4134-3AB00- ... (10 A)
6EP4136-3AB00- ... (20 A)
6EP4137-3AB00- ... (40 A)
Mean Time Between Failures
SN29500: > 320000 h at 40 °C, rated load, 24h operation
