3.3 SIMATIC STEP 7 in the TIA Portal
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
67
3.3.9
Diagnostics
The following data can be retrieved using the online and diagnostics function:
Navigation area
Value
General Module
Short designation
Article number
Hardware
Firmware
Module information
Device name
Module name
Plant designation
Location ID
Manufacturer information
Description of manufacturer
Serial number
Copyright entry
Profile
Profile details
PROFINET interface Ethernet address / network connec-
tion
MAC address
Ethernet address / IP parameter
IP address
Subnet mask
Default router
IP settings
IP setting time
Ports
List of ports
Functions Assign an IP address
MAC address
IP address
Subnet mask
Router address
Firmware update / UPS1600 Article number
Firmware
Name
Rack
Slot
Firmware file
Firmware version
Suitable for modules with
Status
Activate firmware after update
Assign name
PROFINET device name
Type
Reset to factory settings
MAC address
IP address
