Siemens 6EP4135-0GB00-0AY0

Installation
7.7 Maintenance
SITOP UPS1600 / UPS1100
208 Manual, 04.2017, A5E37775406-8-76
7.7
Maintenance
7.7.1
Battery
SITOP UPS1100 devices contain 2 maintenance-free batteries.
Device type
Battery type
6EP4131-0GB00-0AY0 (1.2 Ah)
YUASA NP1,2-12
6EP4132-0GB00-0AY0 (2.5 Ah) Hawker Energy CYCLON 0810-0075 2.5-12
6EP4133-0GB00-0AY0 (3.2 Ah)
YUASA NP3,2-12 or B.B.Battery BP3,6-12
6EP4133-0JB00-0AY0 (5 Ah) NEC ALM12V7s
6EP4134-0GB00-0AY0 (7 Ah)
YUASA NP7-12 or B.B.Battery BP7-12
6EP4135-0GB00-0AY0 (12 Ah)
YUASA NP12-12 or B.B.Battery BP12-12
When replacing the batteries, always use batteries with the same batch number
(approximately the same charge state).
The rechargeable batteries must be disposed of, discharged according to the applicable
regulations.
When storing, installing and operating the buffer batteries, the regulations of VDE 0510 Part
2 / EN 50272-2 or the applicable national regulations must be observed.
The self-discharge rate of the batteries is approx. 3%/month for a temperature of 20° C. This
value is temperature dependent and becomes more unfavorable for an increasing
temperature, and more favorable for a decreasing temperature.
7.7.2
Battery replacement
See Figure 7-5 Maintenance (Page 209) and Figure 7-6 Wiring schematic (Page 209)
1. Remove the screws
⑨ using a Torx T10 screwdriver.
2. Open the cover.
3. Press button
⑧ for at least 2 s.
LED
④ flashes
4. Remove fuse
③
5. Replace the batteries.
6. Press the button for at least 2 s
LED
④ stops flashing and lights continuously.
7. Insert the fuse.
8. Close the cover (screw).
