Engineering and remote access
3.4 SIMATIC STEP 7
SITOP UPS1600 / UPS1100
82 Manual, 04.2017, A5E37775406-8-76
● Log off automatically after 15 minutes
You define whether a user should be automatically logged off after closing the web
server.
● Update interval
You define in which intervals the actual values are sent to the web server.
Loading the configuration to the SITOP UPS1600 (commissioning)
In the delivered state, the SITOP UPS1600 has not yet been assigned any IP address and
the DHCP protocol is deactivated.
When the SITOP UPS1600 is first connected with an IO controller (SIMATIC S7 control
system), it must be assigned a device name and an IP address by the IO controller. STEP 7
can be used to load a new configuration to the device.
● The SITOP UPS1600 has been correctly connected and linked with the system.
● PG/PC with SIMATIC STEP 7 is connected with the network.
Displaying accessible nodes
Note
If nodes can only be accessed via interposed switches or routers (
with protocol conversion),
they are not displayed in the list of the accessible nodes.
1. Click in menu "Target system" on "Display accessible nodes".
The "Accessible nodes" window is opened with the following displays:
– Station
– SITOP UPS1600
The following table shows which information is displayed in the "Object name" column.
S7-CPU, PC station Name of the station The "Details" view also shows the operating state, module
type and, if available, information from the associated STEP
7 project (station name, CPU name, system identification).
Loading the IO controller for the first time
Once you have configured the SITOP UPS1600 and the station, you must load this
configuration to the IO controller (SIMATIC S7 control system). This is the way that the IO
controller is assigned its configured IP addresses.
Before loading, carry out a consistency test to check the configuration for duplicate
addresses, identical names, etc.
