Engineering and remote access
3.6 SITOP UPS Manager
SITOP UPS1600 / UPS1100
132 Manual, 04.2017, A5E37775406-8-76
1. Select "Display > Trend diagram".
2. Select "Base Unit" to display trend diagrams for SITOP UPS1600 values
or
select "Energy storage" to display trend diagrams for the energy storage device values.
3 diagrams are available below both points.
3. Click the appropriate button to display the required trend diagram.
Determining the firmware version
The firmware version of the SITOP UPS1600 can be determined as follows using the UPS
Manager:
The SITOP UPS1600 is connected to your PC via USB.
Also possible for a connection via Ethernet with software version> V2.0 - and manager
version > 4.60.1
