Description, device design, dimension drawing
2.4 Operating displays and signaling
SITOP UPS1600 / UPS1100
36 Manual, 04.2017, A5E37775406-8-76
2.4.2
SITOP UPS1100
2.4.2.1
LEDs
6EP4131-0GB00-0AY0 (1.2 Ah)
6EP4132-0GB00-0AY0 (2.5 Ah)
6EP4133-0GB00-0AY0 (3.2 Ah)
6EP4133-0JB00-0AY0 (5 Ah)
6EP4134-0GB00-0AY0 (7 Ah)
6EP4135-0GB00-0AY0 (12 Ah)
Status display
LED battery
Figure 2-16 6EP4131-0GB00-0AY0 example
Table 2- 6 LED ④ battery
Signaling
6EP4131-0GB00-0AY0 (1.2 Ah)
6EP4132-0GB00-0AY0 (2.5 Ah)
6EP4133-0GB00-0AY0 (3.2 Ah)
6EP4133-0JB00-0AY0 (5 Ah)
6EP4134-0GB00-0AY0 (7 Ah)
6EP4135-0GB00-0AY0 (12 Ah)
Flashing green
(0.5/0.5)
Error or alarm, battery replacement initiated
Off
Battery off, no communication
Green
Battery OK
