Description, device design, dimension drawing
2.4 Operating displays and signaling
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
35
:
30 V AC/0.5 A 60 V DC/0.3 A 30 V DC/1 A
Note
From the instant in time when the SITOP
UPS1600 is switched over into the buffer mode, for
the evaluation, instead of the expected buffer current, the actually measured buffer current is
used. As a consequence, the status of the LEDs and
the relay can also change.
